| Model | Product Name |
Product size（mm) |
Rated Voltage(V) |
Current Consumption(mA) |
SPL(dB) | Operating Voltage(V) |
Operating Temperature(℃) |
Weight(g) | Carton Size(cm) |
Quantity(pcs) | Gross Weight(Kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
Piezo Passive SMD Buzzer YN-YDW9018-4012 | 9*9*1.8mm | 3/5/12V | ≤5mA | ≥75dB | 1-24V | -20～+70℃ | 0.2g | / | / | / |
 |
Piezo Passive SMD Buzzer YN-YDW1003-5205S | 10*10*3mm | 5V | ≤3.5mA | ≥70dB | 1-20V | -20～+70℃ | 0.4g | / | / | / |
 |
Piezo Passive SMD Buzzer YN-YDW1109-4112SB | 11*9*1.7mm | 3/5/12V | ≤3.5mA | ≥70dB | 1-25V | -20～+70℃ | 0.4g | / | / | / |
 |
Piezo Passive SMD Buzzer YN-YDW1203-4005SB | 13*13*5.5mm | 3/5/12V | ≤5mA | ≥75dB | 1-25V | -10～+60℃ | 1g | / | / | / |
 |
Piezo Passive SMD Buzzer YN-YDW13025-4112S | 13*13*2.5 | 3/5/12V | ≤5mA | ≥85dB | 1-25V | -20～+70℃ | 0.3g | / | / | / |
 |
Piezo Passive Buzzer YN-YDW12055-40P-6.5 | 12*5.5mm | / | ≤5mA | ≥80dB | 3~30V | -20~+70℃ | 1g | / | / | / |
 |
Piezo Passive SMD Buzzer YN-YDW1708 | 17*8mm | 12V | ≤18mA | ≥90dB | 3~16V | -30～+70℃ | 3.2g | / | / | / |
 |
Piezo Passive SMD Buzzer YN-YDW2207-4012S | 22*7mm | 12V | ≤12mA | ≥95dB | 1~30V | -30~+85℃ | 2.3g | / | / | / |
 |
Piezo Passive SMD Buzzer YN-YDW1404-4012 | 14.1*14.1*4.3mm | 3/5/12V | ≤5mA | ≥80dB | 2~25V | -20~+70℃ | 1.6g | / | / | / |
